Product Features
● Precision linearity
● Long mechanical life
● High resolution
● Small dynamic noise
● Convenient and reliable installation
| Standard Resistance | 1KΩ、2KΩ、3KΩ、5KΩ、10KΩ |
| Resistance Tolerance | ±15% |
| Independent Linearity | 0.1%、0.2%、0.3%、0.5%、1% |
| Electrical Travel | 300° ± 2° |
| Power Rating | 2W(70°C) |
| ResistTemperature Coefficient | ≤±0.04%/℃ |
| Insulation Resistance | ≥1000KΩ ( 500VD.C) |
| Dielectric Strength | 1000V ( AC.RMS)1min |
| Output Smoothness | ≤+0.1% |
| Mechanical Travel | 360° (endless ) |
| Starting Torque | ≤10*10 -4N.M |
| Life Expectancy | 50*106cycle |
| Operating Temperature | -55°C~+125°C |
| Vibration | 15G 2000HZ |
| Shock | 50G 11ms |
Shaft Length,Diameter,stopper,special electrical travel,Special machining on the shaft.
HuiRen Electronic is proud to be one of the leader of condustive plastic potentiometer , Industrial joystick.
