Product Features
● Spring automatically resets.
● Single-axis, dual-axis, and multidirectional operation.
● Can be operated with a single button.
● Simple structure and easy installation
● High-quality imported switch, rated for 250V 3A/125V 5A current.
Application
The SJ800 industrial joystick is suitable for various systems, including electric vehiclemotion control, electric wheelchair control, robotics, human-machine remote videooperation systems, industrial control, heavy-duty mobile machinery, measurementsystems, navigation systems, studio stage lighting equipment, and military equipment.
| Storage | temperature | -25°C~+80°C |
| Operating | temperature | -25°C~+80°C |
| Mechanical angle | Hall:士20° |
| Operating torque | 1N ( 50Nmax) |
| Mechanical life | 5 million |
| Mechanical error | 士0.5° |
| Hall | |
| Power supply voltage | 125V/5A 250V/3A |
Huiren Electronic гордится тем, что является одним из лидеров в области проводящих пластиковых потенциометров и промышленных джойстиков.
