Product Features
● Precision linearity
● Long mechanical life
● High resolution
● Small dynamic noise
● Convenient and reliable installation
| Standard Resistance | 1KΩ~10KΩ |
| Resistance Tolerance | ±15% (standard ) ±1% (precision ) |
| Independent Linearity | ±1% (standard ) ±0.1% (precision ) |
| Electrical Travel | 345° ± 2°(special angle is available ) |
| Power Rating | 2W(70°C) |
| ResistTemperature Coefficient | ±400p.p.m./°C |
| Insulation Resistance | ≥1000KΩ ( 500VD.C) |
| Dielectric Strength | 1000V ( AC.RMS)1min |
| Output Smoothness | ≤+0.1% |
| Mechanical Travel | 360° (endless ) |
| Starting Torque | ≤10*10 -4N.M |
| Life Expectancy | 50*106cycle |
| Operating Temperature | -55°C~+125°C |
| Vibration | 15G 2000HZ |
| Shock | 50G 11ms |
HuiRen Electronic is proud to be one of the leader of condustive plastic potentiometer , Industrial joystick.
